High-Efficiency 6-Heatpipe Design
The core of the MX-96-V3 is built with six 6mm high-performance copper heatpipes that utilize direct-contact technology. This allows for rapid heat transfer from the CPU surface directly into the high-density aluminum fin stack. Whether you are gaming, editing, or multitasking, this cooler ensures your system maintains peak performance without thermal throttling.
Smart PWM Cooling & Quiet Operation
Equipped with a 92mm PWM fan, the Snowman MX-96-V3 intelligently adjusts its speed between 800 and 2300 RPM based on your CPU’s temperature. This ensures a perfect balance between high-airflow cooling (42 CFM) and silent operation. The advanced Hydraulic Bearing further reduces friction, providing a longer lifespan and quieter acoustics compared to standard fans.
Compact Tower with Universal Compatibility
Standing at only 119mm tall, the MX-96-V3 is designed to fit into a wide variety of chassis, including many Small Form Factor (SFF) and Mini-Tower cases where larger coolers might fail. It features a universal mounting system, making it fully compatible with the latest platforms including Intel LGA 1700 and AMD AM5.
Vibrant RGB Aesthetics
Add a touch of style to your build with integrated RGB lighting. The fan illuminates your internal components with bright, multi-color effects, making it an ideal choice for builds with tempered glass side panels.
Key Features:
-
6 Pure Copper Heatpipes: Maximum heat conductivity for superior cooling performance.
-
PWM Intelligent Speed Control: Dynamically adjusts speed from 800 to 2300 RPM.
-
Ultra-Compact Height: At only 119mm, it offers excellent compatibility with smaller PC cases.
-
High-Pressure Airflow: 92mm fan provides 42 CFM to dissipate heat quickly.
-
Ready for Modern Sockets: Supports Intel LGA 1700 and AMD AM5 out of the box.
-
Low Power Consumption: Efficient motor design uses only 1.2W of power.
Technical Specifications:
| Feature | Specification |
| Product Size | 76(L) x 92(W) x 119(H) mm |
| Heat Pipes | 6 x 6mm Units |
| Fan Size | 92 x 92 x 25 mm |
| Fan Speed | 800 – 2300 RPM ±10% |
| Air Flow | 42 CFM |
| Bearing Type | Hydraulic Bearing |
| Voltage / Current | 12V DC / 0.1A |
| Power Consumption | 1.2W |
| Connector | 4-Pin PWM / RGB |
Compatibility (Socket Support):
-
Intel Sockets:
-
LGA 1700 / 1200 / 1150 / 1151 / 1155 / 1156
-
LGA 1356 / 1366
-
LGA 2011 / 2066
-
-
AMD Sockets:
-
AM5 / AM4
-
AM3+ / AM3 / AM2+ / AM2
-
FM2 / FM1
-
What’s in the Box:
-
1 x Snowman MX-96-V3 CPU Cooler
-
1 x Multi-platform Mounting Bracket Kit
-
1 x High-Performance Thermal Paste sachet
